Dimensions (Lx W x H): 356190353mm
Net weight (kg): 50kg
Nominal voltage: 12.8V
Charging voltage: 14.6V
Mode of communication: Integrated Bluetooth 4.0 module
Protection Index: IP62
Maximum charging current: 250A
Maximum continuous discharge current: 300A
BMS (Battery Management System): Integrated
Number of cycles: >6000 @ 80% DoD
Nominal capacity @ 25°C: 500Ah / 6400Wh
Temperature range (discharge): -20 ~ 75 °C
Temperature range (load): -35 ~ 50 °C
Temperature range (storage): -5 ~ 35 °C
Terminal: M8
connection: Max. 4 Series and 4 Parallel Connections
