Experience unparalleled boating with our E-Series batteries, expertly designed for compatibility with ePropulsion’s Spirit, Navy, and POD motors. Offering consistent, high-quality power and sustainable technology, these batteries redefine marine propulsion for today’s mariner.
3 456,25 € + vat
|
E163 |
|
| Capacity | 8345 Wh / 163 Ah |
| Rated Voltage | 51.2 V |
| Battery Life | 3,000 cycles at 80% SoH |
| Weight | 76 kg |
| Dimensions | 470 x 295 x 495 mm
(18.5 x 11.6 x 19.5 in) |
| Cut-off Voltage | 41.6 V |
| Final Charging Voltage | 57.6 V |
| Max Continuous Discharging Current | 150 A |
| Series Connection | N/A |
| Parallel Connection | Up to 16 |
| Cell Configuration | 16S1P |
| Charger | E-Series battery charger |
| Charging Time (220V) | One charger: 7.2 Hrs
Two chargers: 3.6 Hrs |
| Charging Time (110V) | One charger: 11 Hrs
Two chargers: 5.4 Hrs |
| Charging Temperature | 0 to 55℃ (32 to 131˚F) |
| Discharging Temperature | -10 to 60℃ (14 to 140˚F) |
| Communication | Available: CAN-Bus for Parallel
RS485 for ePropulsion motors |
| Shipping Classification | UN3480, Class 9, UN38.3 Certified |
| Approvals | CE, UKCA, FCC |
| Warranty (Non-Commercial Use) | 2 years |
| Weight | 76 kg |
|---|
